This component was introduced in OS/2 EE 1.2. It is where the users Logon to have access to other services like LAN Requester or Database Manager.

IBM OS/2 User Profile Management is located in the \MUGLIB\ directory.

API

Function Calls

16-bit 32-bit
UPMELOCL U32ELOCL Invokes UPM to display a local logon window.
UPMELOCU U32ELOCU Retrieves an ID of a local user that already is logged on to the system.
UPMEULGF U32EULGF Logs a user off the system.
UPMEULGN U32EULGN Logs on a user.
UPMEUSRL U32EUSRL Returns a list of logged-on user IDs.

Data Types

  • LSFAR

UPM Logon Data Structure

struct upm_user_logon {
   unsigned char       userid [UPM_UIDLEN + 1];
   short               remotetype;
   unsigned char       remotename [UPM_REMLEN + 1];
   LSINT               sessionid;
};

Return Codes

Symbolic Constant Meaning
UPM_ACTIVE The domain logon or logoff failed. A domain logon, logoff or the LAN Requester GUI is active.
UPM_BAD_PARAMETER The remote name is not valid.
UPM_BAD_TYPE The remote type specified is not valid.
UPM_ERROR_MORE_DATA All the available UPM_USER_LOGON entries did not fit into buf.
UPM_FAIL_SECURITY The user ID or remote name could not be validated.
UPM_LOG_CANCEL The user is cancelled from the logon panel.
UPM_LOG_FILE_NOT_FOUND A required logon program was not found.
UPM_LOG_INPROC Another logon was being processed, the logon attempt was not successful.
UPM_LOGGED The domain logon failed because a domain logon has already occurred.
UPM_NOMEM Insufficient memory is available to process the request.
UPM_NOT_LOGGED The user has not logged on locally.
UPM_OK The user was logged on successfully.
UPM_OPEN_SESSIONS The domain logoff failed because a domain logon has active open sessions.
UPM_PASSWORD_EXP The logon failed. The user's password is expired.
UPM_SS_BUSY The local logon failed. The secure shell was busy.
UPM_SS_DEAD The local logon failed. The secure shell has stopped.
UPM_SS_PWDEXPWARNING The local logon succeeded. The user's password is expired.
UPM_SYS_ERROR An unexpected system error occurred.
UPM_ULP_LOADED The local logon failed. A local logon with a user logon profile is already active.
UPM_UNAVAIL The local logon failed. The remote node or domain could not be contacted to process the logon request.

Files

\MUGLIB
Name Comments
LANLOGON.ICO icon for LAN logon
LOGOFF.EXE logoff
LOGOFF.ICO icon for logoff
LOGON.EXE logon
LOGON.ICO icon for local logon
LOGONIBM.EXE
MUGACCTS.EXE
MUGLEXEC.EXE
MUGLRQST.EXE
MUGMSG.MSG messages
MUGW.HLP help
MUGWEPOP.EXE
MUGWLOGF.EXE
SYSLEVEL.MUG
SYSLEVEL.UPE
UPM.CB
UPM.FOR
UPM.INC include
UPMACCTS.EXE account management
UPMACCTS.ICO icon for account
UPMCSET.EXE
UPMFLDR.ICO icon for folder
\MUGLIB\DLL
Name Comments
MAILSLOT.DLL Mailslot APIs provide one-way interprocess communication (IPC).
MUG.DLL
NETAPI.DLL LAN Manager Library. Also operates on the basis of the OS/2 and NBF protocol
NETAPI32.DLL
NETAPINC.DLL
NETOEM.DLL
NETSPOOL.DLL
UPM.DLL
UPM32.DLL

Publications

  • GG24-3559-00 - IBM OS/2 Extended Edition 1.2 Cookbook: Database Manager - User Profile Management - 1990
